Non-insulated cost-effective system with slim design

MU100 Special

MU100 Special is a reliable, established and cost-effective sliding system available without thermal insulation. Combining slim linear design with easy installation and essential system versatility, system MU100 Special is the perfect affordable solution for renovations or new constructions.

Technical Features & Solutions

  • MU100 Special is characterized by excellent air and water tightness, increased acoustic insulation and mechanical strength.
  • The system has a slim, simple and modern design with a very slim interlock section of only 26.4 mm.
  • The system covers all possible frame configurations, single, double, triple and quadruple sashes, with 90° mullion free closing and with or without fly screens. The system can also be concealed in walls and floors for a slim look.
  • MU100 Special is quick and easy to assemble and install, combining safety and functionality, without requiring high investment costs, making it ideal for renovations.
  • High security is achieved with multiple locking points and high-tech precision accessories. A variety of high quality handles, embedded handles and mechanism are available from MUSKITA, Giesse Italy and G-U Germany.
Back
Technical Characteristics
Rail Width
96.5 mm
Rail Height
25 & 35 mm
Sash Width
33.5 & 37 mm
Sash Height
63, 66.5 & 90 mm
Interlock Section Width
36 & 56 mm
Maximum Sash Weight
200 kg
Glass Options
Up to 24 mm
Performance & Classification
Air Permeability
Class 3
Water Tightness
Class 4B
Resistance to Wind Load
Class A3
Finishes & Colours
Anodize
anodize
Powder Coating
powder coating
Sublimation & Wood Finishes
wood
Cross Sections
MU100 Special
