Τhe ultimate thermal system with outstanding energy and safety ratings

MU2075 Elite

MU2075 Elite is the ultimate comprehensive hinged system featuring outstanding energy efficiency, sound reduction and safety performance ratings. Combining elegant linear design with robust construction, easy installation and essential system versatility, MU2075 Elite covers all possible configurations offering multi-locks, as well as micro-ventilation for even the most demanding projects.

Technical Features & Solutions

  • The system’s impressive performance ratings make it ideal for private residences and buildings with high energy requirements. Outstanding energy efficiency ratings are achieved with polyamides, special insulating materials within the profile and specially designed concealed plastic inserts.
  • Excellent sound reduction properties and top performances in water tightness and air permeability even in extreme weather conditions, accomplished by triple sealing via multicavity central and expandable EPDM gaskets.
  • Microventilation options available for simple,  effective and safe room ventilation achieved by opening the sash only a few millimeters, allowing air to flow naturally without any sudden changes in temperature.
  • Combines robust construction with essential system versatility and functionality.
  • Easy and quick installation.


Excellent versatility with vast design capabilities and solutions for every possible configuration:

  • MU2075 Elite covers all possible frame configurations from standard to Tilt & Turn, Tilt & Slide or Pivot Door and window options, double active doors, as well as shopfronts or projected sashes for even the most demanding projects.
  • Ability to combine single, multi-sash or fixed frames.


High-security:

  • High security achieved with multiple locking points and high security customized hardware.
  • Tested and certified for excellent burglar-resistance with one of the highest RC3 burglar-resistance category certifications.
  • Compatible with both Camera Europea multiple locking hardware and Camera ALU16 perimetric locking hardware.
Back
MU2075 Elite 2
Technical Characteristics
Frame Width
78 mm
Sash Width
85 mm
Minimum Aluminium Visible Width
85.4 mm
Minimum Aluminium Visible Width of T-profile
74 mm
Maximum Sash Weight
170 kg
Glass Options
Up to 66 mm
Performance & Classification
Thermal Transmittance – Uw [W/(m2K)]
≥ 1.0
Sound Reduction
51 dB
Air Permeability
Class 4
Water Tightness
Class E1050
Resistance to Wind Load
Class C5
Finishes & Colours
Learn More
Anodize
anodize
Powder Coating
powder
Sublimation & Wood Finishes
wood
Configurations
Opening, Tilt & Turn Window or Door with Fixed Panel
One Sash Window/ Door
one sash
Two Sash Window/ Door
two sash
Three Sash Window
three sash
Cross Sections
4
